Description
- 13:1 Pump Size
- Cart, stand and wall mount options
- Can also be purchased with gun and hoses
<– MORE DETAILS
Anest Iwata MSU-11N 13:1 Air-Assisted Airless Pump
$2,916.98 – $4,343.44
An excellent entry-level air-assisted airless pump offering cart, wall and stand mount options.
| TECHNICAL | ||||
| Pressure Ratio | Max. Fluid Pressure (bar/psi) |
Max Air Pressure (bar/psi) |
Max Fluid Delivery (qt/min) |
Suction Filter Mesh |
| 13:1 | 88 / 1,276 | 6.8 / 98 | 2.0 | 50 |
| ACCESSORIES | |
| Code | Description |
| 7956 | AIR MOTOR REPAIR KIT (includes: 4, 6, 16, 17, 20, 31, 34 ) |
| 7967 | PUMP REPAIR KIT – MAJOR MAINTENANCE (includes: 44, 45, 46, 48, 49, 50, 52, 55, 56, 57) |
| 7968 | PUMP REPAIR KIT – MINOR MAINTENANCE (includes: 45, 49, 51, 52, 55, 56, 57) |
| 04407070 | PP7131N PLUNGER PUMP ONLY |
| 04931360 | MSU PUMP BASE SET W/ AIR REGULATOR SET |
| 04320150 | MSU CART FRAME SET |
| SERVICE PARTS | ||
| Ref. | Code | Description |
| 1 | 4401051 | AIR CYLINDER |
| 2 | 4437050 | CAP NUT |
| 3 | 4444050 | WASHER |
| 4 | 9447080 | PACKING |
| 5 | UL300800 | WASHER |
| 6 | 96630022 | O-RING |
| 7 | 94492050 | SPINDLE SET |
| 8 | 4438081 | SPECIAL JOINT |
| 9 | 6805480 | JOINT NUT |
| 10 | 6806480 | SLEEVE |
| 11 | 4486052 | HOSE |
| 12 | 6613240 | STOPPER |
| 13 | 4444090 | WASHER |
| 14 | 4449080 | PACKING |
| 15 | 4459051 | STOPPER |
| 16 | 96634060 | O-RING |
| 17 | 94488051 | BLOCK |
| 18 | 4406051 | GUIDE PLATE |
| 19 | 4405060 | SEAT BLOCK |
| 20 | 96634045 | O- RING |
| 21 | 6800481 | ELBOW UNION |
| 22 | 94402050 | EXHAUST MUFFLER |
| 23 | 4405051 | EXHAUST COVER |
| 24 | 6154073 | SCREW |
| 25 | 96500406 | SPRING WASHER |
| 26 | 6136614 | BOLT |
| 26-1 | UL300820 | SPRING WASHER |
| 27 | 4943051 | MAIN BODY SET |
| 28 | UL300811 | SPLIT PIN |
| 29 | 4400080 | ADAPTOR |
| 30 | 6131308 | SCREW |
| 31 | 94488061 | BLOCK CARRIER |
| 32 | 4457062 | INTERLOCK PIECE |
| 33 | 4457090 | INTERLOCK END PIECE |
| 34 | 4428050 | WASHER |
| 35 | 94412060 | SPRING |
| 36 | 4458070 | CAP |
| 37 | 171002010 | CONNECTING ROD |
| 38 | UL300802 | SPRING WASHER |
| 39 | UL300703 | HEXAGON NUT |
| 40 | 448310100 | SUCTION MAIN BODY |
| 41 | 94403080 | ROD |
| 42 | 4404080 | THINNER CUP SET |
| 43 | 94022090 | SLEEVE |
| 44 | 94404090 | V PACKING FEMALE UPPER ADAPTOR |
| 45 | 94932100 | UPPER V PACKING SET |
| 46 | 94405090 | V PACKING MALE UPPER ADAPTOR |
| 47 | 4407050 | NUT |
| 48 | 94408050 | V PACKING MALE LOWER ADAPTOR |
| 49 | 94930100 | LOWER V PACKING SET |
| 50 | 94410050 | V PACKING FEMALE LOWER ADAPTOR |
| 51 | 96662025 | BALL |
| 52 | 94447600 | PACKING |
| 53 | 94461100 | VALVE HOLDER SET |
| 54 | 4411050 | SUCTION TUBE |
| 55 | 94420600 | PIN |
| 56 | 94447610 | PACKING |
| 57 | 96662050 | BALL |
| 58 | 94407060 | VALVE ADAPTOR SET |
| 59 | UM43060900 | FLUID OUTPUT JOINT |
| 60 | ME100001 | GROUND WIRE |
| 61 | UL30036000 | SAFETY VALVE |
| 62 | UL30030000 | “T” JOINT |
| 63 | UL300309 | “L” QUICK COUPLING |
| 64 | 4413050 | SPRING |
Additional information
| Weight | 0.01 lbs |
|---|---|
| Dimensions | 3.9 × 3.9 × 3.9 in |
| Pump Type | Air-Assisted Airless |
| Pressure Ratio | 13:01 |
| Mount Type | Cart, Wall, Stand |
| Water Compatible | Yes |
| Fluid Regulator | Yes |
| Air Regulator | Yes |
| Fluid Thread Size | G1/4" |
| Fluid Thread Type | Male |
| Air Thread Size | G1/4" |
| Air Thread Type | Male |
| Gun Included | No, Yes |
| Hoses Included | No, Yes |
