ANest Iwata PET-10 2.6 gallon pressure pot
Anest Iwata PET10 - 2 GALLON PRESSURE TANK - Image 2

Anest Iwata PET10 – 2 GALLON PRESSURE TANK

$510.09

With 2.6 gallon capacity, dual regulators and a removable stainless steel liner, this pressure pot offers all the features you need? for your next large job.

SKU: 6315 Categories: , Tag:

Description

  • 2.6 Gal Capacity
  • Dual Regulators
  • Removable stainless steel lines
  • Available disposable liners

<– MORE DETAILS

TECHNICAL
Capacity Max.  Working Pressure
(bar/psi)		 Working Temperature
(deg F)
2.6Gal 4.0 / 58.0 41-104
ACCESSORIES
Code Description
4020170 REMOVABLE STAINLES STEEL TANK LINER

SERVICE PARTS
Ref. Code Description
1 4020000 MAIN BODY
2 4020010 LID ASSEMBLY
3 4020200 LID PACKING
4 4020020 HANDLE
6 4020030 EXHAUST VALVE
7 94020210 AIR INLET JOINT / OUTLET JOINT G1/4”
10 94015180 PRESSURE REGULATOR (FOR TANK)
22 4016390 SAFETY VALVE
24 4020040 FLUID OUTLET CONNECTING JOINT SUS 303
25 4016020 PRESSURE GAUGE
29 4020190 HANDLE BOLT
30 4020060 WASHER
31 4020070 THUMB NUT
32 4020220 C-SNAP RING
33 4020230 STUD
34 4020090 SUCTION PIPE SUS 303
39 94016310 AIR FLOW GUIDE
45 94020100 ADAPTER
46 94020110 ADAPTER
47 94020120 ADAPTER
48 4020130 PRESSURE REGULATOR (FOR GUN)
49 4020140 FLUID OUTLET JOINT SUS 303  3/8”
50 4020160 NUT
51 4020170 INNER TANK SUS 304

Additional information

Weight 28 lbs
Dimensions 21.3 × 10.3 × 10.3 in
Pressure Ratio

1:01
Water Compatible

Yes
Fluid Regulator

Yes
Air Regulator

Yes
Fluid Thread Size

G3/8"
Fluid Thread Type

Male
Air Thread Size

G1/4"
Air Thread Type

Male
Container Size

2.6 Gal
